Hose types
Hose types can be added/edited or deleted in this form.
| Field | Description |
|---|---|
| Indicates the article type as follows: (HRID maps the type specification for the PLC, also to be specified during import)  |
|
| Assignment of a suitable name for the article group (e.g. manufacturer designation) |
|
| Indicates the coupling of the associated articles | |
| Indicates the standard length of the assigned article | |
| Indicates the default inside diameter of the associated articles | |
| Selection of a color which should be assigned to the linked articles when they are created main menu -> master data -> value lists (entry) |
|
| Selection of a material that should be assigned to the linked articles when creating it Main menu -> Master data -> Value lists (entry) |
|
| Indicates the check interval of the assigned articles (Is calculated automatically after a check) |
|
| Indicates the type of winding for pressure hoses (single, half) |
|
| Not transmitted to PLC | If the switch is set, no message is sent to the PLC to check the article during a check |
Note: Article groups only show the recipe number, since the name can be freely changed via the system. Recipe names can be changed via the system and transferred to the application.
